Position Sensing Magnets

Application support for magnets used in linear, angular, open/closed, and end-position detection systems.

Target Buyer:Best for engineering teams designing magnetic position sensing into a new device or replacing an unstable magnet source.

Position Sensing Magnets application reference selected from the sensor magnet image library.

Solution Highlights

Match magnet geometry and magnetization direction to the movement path
Evaluate air gap variation, housing tolerance, and sensor mounting offset
Review whether the application needs a loose magnet, insert, or assembly
Define sample tests for switching distance, repeatability, and temperature behavior

Evaluation Metric	Typical Range	Buyer Relevance
Air gap window	Defined by sensor and housing stack-up	Air gap variation often drives whether a magnet passes or fails in final assembly.
Switching or output repeatability	Buyer-defined acceptance window	Stable output is more important than nominal magnet strength alone.
Assembly datum	Drawing-defined reference feature	A clear datum prevents polarity and offset errors during production.

Prototype works but production stack-up fails: Review worst-case tolerance stack-up and test samples in real housings.
Sensor axis and magnet axis mismatch: Confirm magnetic orientation against the sensor package before ordering samples.

Related magnet and assembly visuals selected by application filename match. Confirm final fit through buyer-side fixture validation.

Yes. We can start with the target distance, sensor type, and space limit, then narrow options for prototype testing.

Yes. A carrier or assembled magnet can reduce buyer-side polarity and positioning risk.

Inquiry Email

Include drawing, dimensions, material, coating, magnetization, quantity, and delivery location.

Instant Chat

+86 18857971991

Direct channel for RFQ details and engineering clarification.

Application Evaluation Matrix

Evaluation Metric	Typical Range	Buyer Relevance
Air gap window	Defined by sensor and housing stack-up	Air gap variation often drives whether a magnet passes or fails in final assembly.
Switching or output repeatability	Buyer-defined acceptance window	Stable output is more important than nominal magnet strength alone.
Assembly datum	Drawing-defined reference feature	A clear datum prevents polarity and offset errors during production.

Buyer FAQ

Yes. We can start with the target distance, sensor type, and space limit, then narrow options for prototype testing.

Yes. A carrier or assembled magnet can reduce buyer-side polarity and positioning risk.
